The complete solution for generator automation, monitoring, and remote control. Perfect for off-grid cabins, RVs, boats, and backup power systems.
The complete solution for generator automation, monitoring, and remote control. Perfect for off-grid cabins, RVs, boats, and backup power systems.
Monitor and control your generator from anywhere in the world. Full-featured web dashboard with color-coded gauges showing battery voltage, oil pressure, coolant temperature, fuel level, RPM, and AC power - accessible via our secure cloud portal or local network. No VPN setup, no port forwarding required.
Comprehensive monitoring of oil pressure, coolant temperature, and RPM with automatic shutdown on fault conditions. Configurable thresholds and all events logged with timestamps.
Advanced glow plug control with one-button auto-calibration. Learns your plugs' hot/cold resistance and automatically adjusts preheat timing. Supports 1-4 glow plugs with 35A PWM output and real-time current monitoring.
Built-in 60W smart charger keeps your starting battery topped up with inverter or solar power. 3-stage charging with automatic cutoff on alternator detection.
Commercial-grade power monitoring with 0.1% accuracy. Real-time display of voltage and frequency - know exactly what your generator is producing.
Temperature-controlled preheat relay for block heaters. Automatically activates based on coolant temperature with configurable thresholds and safety time limits.
Start your generator via remote input, web dashboard, Home Assistant automation, or front panel controls. Configurable voltage thresholds, retry limits, and cooldown delays for reliable unattended operation.
Vibrant 128Ć128 full-color OLED display with rotary encoder navigation. Shows real-time gauges, system status, and menu-driven configuration - no phone or computer needed.
Native MQTT integration with auto-discovery. Your IntelliAGS appears automatically in Home Assistant with all sensors and controls ready to use - no manual configuration required.
Dual network connectivity with automatic failover. If WiFi drops, the system seamlessly switches to Ethernet - and vice versa - ensuring constant connectivity in remote installations.
Over-the-air firmware updates via web interface or remote portal, with local drag-and-drop capability as well. Keep your system current without physical access.
Dual storage with onboard eMMC flash plus MicroSD card slot. Logs all sensor data in CSV format with NTP time sync. Configurable sample rates from 250ms to 2 seconds.
| Cranking | Configurable start sequence |
|---|---|
| Engine Protection | Oil, coolant, overspeed limits |
| Battery & Fuel | Low voltage/fuel start lockout |
| Glow Plug | PWM or SmartGlow auto-calibration |
| Postglow | Crank assist up to 10 minutes |
| Block Heater | Temperature-controlled preheat relay |
| Start Signal | Opto, alternator D+, or both |
| Data Logging | Configurable sample rate & storage |
| System Options | WiFi power, timezone, charger boot |
| Glow Plug OUT | PWM 35A, current sensed |
|---|---|
| Starter OUT | On/Off 15A, protected |
| Fuel Cut OUT | On/Off 15A, protected |
| Fuel Pump OUT | On/Off 15A, protected |
| Preheat Relay OUT | On/Off 15A 120VAC, temp controlled |
| Oil Pressure IN | 0-100 PSI, 0.5-4.5V analog |
| Coolant Temp IN | NTC thermistor, -40 to 125Ā°C |
| Fuel Level IN | 0-190Ī© resistive sender |
| Battery Voltage IN | 10-16V DC, reverse protected |
| RPM / Tach IN | Hall/inductive, 5V NPN |
| Remote Start IN | Opto-isolated, configurable polarity |
| Alternator D+ IN | Charge detection, 12-14V |
| WiFi | Built-in wireless connectivity |
|---|---|
| Ethernet | Wired backup with auto-failover |
| MQTT | Home Assistant ready |
| Web Interface | Browser-based dashboard & config |
| Data Logging | Onboard + removable storage |
| Display | Full-color OLED status screen |
| Input Voltage | Universal AC input |
|---|---|
| Power Supply | Industrial 60W isolated module |
| Charging Output | 2A smart 3-stage charging |
| Battery Types | All Lead-Acid types supported |
| Float Voltage | Configurable float voltage |
| AC Metering | Accurate real-time monitoring |
| Isolation | True galvanic isolation (1200Vpk) |
| Control Logic | Start assist, smart charge, auto-cutoff |
| Dimensions | 178 Ć 300 Ć 57 mm (L Ć W Ć H) |
|---|---|
| Mounting | DIN rail or panel mount |
| Enclosure | IP54 rated (with proper installation) |
| Operating Temp | -40Ā°C to +85Ā°C |
| Storage Temp | -40Ā°C to +105Ā°C |
| Humidity | 0-95% non-condensing |
Detailed explanation of all settings and calibration procedures.
Web interface, dashboard, settings, OTA updates, and remote access.
MQTT integration guide for Home Assistant with example automations.
Detailed schematics for common generator types and configurations.
Common issues and solutions, error code reference, and FAQ.
IntelliAGS firmware is easily updated via the built-in web interface, remotely through Home Assistant, or over the internet via our secure portal. Custom update solutions can be accommodated on request.
Firmware is constantly improved and developed based on valuable feedback from clients and our network of test and development sites. New features, bug fixes, and performance improvements are released regularly.
Contact us for pricing and availability.
